n8n to Lamatic Migration Tool

A production-ready Next.js application that converts n8n workflows to Lamatic format with intelligent node mapping, dependency analysis, and automated conversion.

💡 Try it now: Visit migrate.lamatic.ai (opens in a new tab) to start migrating your n8n workflows

📦 Open Source: Check out the GitHub repository (opens in a new tab) for source code and contributions

Overview

The n8n to Lamatic Migration Tool is a comprehensive solution for migrating your existing n8n automation workflows to the Lamatic platform. It provides intelligent node mapping, automatic dependency resolution, and real-time conversion progress tracking to make your migration seamless and efficient.

Key Benefits

Time Savings: Convert complex workflows in minutes instead of hours or days
Intelligent Mapping: Automatic conversion of 40+ n8n node types to Lamatic equivalents
Dependency Preservation: Maintains workflow connections and execution order
Production Ready: Generates fully functional Lamatic workflows ready for deployment
Comprehensive Reports: Detailed migration analytics and conversion statistics

Features

File Upload

Drag & Drop Interface: Simply drag your n8n JSON file onto the upload area
File Validation: Automatic validation of n8n workflow structure
Size Limits: Supports workflows up to 10MB

Intelligent Node Mapping

Deterministic Conversion: 40+ n8n node types automatically mapped to Lamatic equivalents
Parameter Transformation: Intelligent parameter and credential mapping
Type Preservation: Maintains node functionality and behavior

Dependency Analysis

Connection Mapping: Converts n8n connections to Lamatic dependency structure
Execution Order: Calculates proper node execution sequence
AI Connections: Handles special AI connection types (ai_tool, ai_memory, ai_languageModel)

Real-time Progress

Live Updates: Watch migration progress in real-time
Step Tracking: Detailed progress for each migration phase
Status Indicators: Clear visual feedback on conversion status

Migration Reports

Comprehensive Analytics: Node-by-node conversion details
Warnings & Errors: Detailed information about any issues encountered
Statistics: Conversion success rates and node mapping statistics

Error Handling

Graceful Failures: Detailed error messages with actionable guidance
Warning System: Non-blocking warnings for potential issues
Recovery Suggestions: Helpful tips for resolving migration issues

Supported n8n Nodes

The migration tool supports 40+ n8n node types across multiple categories:

Triggers (4)

✅ Webhook Trigger (n8n-nodes-base.webhook)
✅ Manual Trigger (n8n-nodes-base.manualTrigger)
✅ Schedule Trigger (n8n-nodes-base.scheduleTrigger)
✅ Chat Trigger (@n8n/n8n-nodes-langchain.chatTrigger)

AI & LangChain (6)

✅ Google Gemini Chat Model (@n8n/n8n-nodes-langchain.lmChatGoogleGemini)
✅ OpenAI Chat Model (@n8n/n8n-nodes-langchain.lmChatOpenAi)
✅ Groq Chat Model (@n8n/n8n-nodes-langchain.lmChatGroq)
✅ Window Buffer Memory (@n8n/n8n-nodes-langchain.memoryBufferWindow)
✅ Memory Manager (@n8n/n8n-nodes-langchain.memoryManager)
✅ LangChain Agent (@n8n/n8n-nodes-langchain.agent)

Database & Tools (3)

✅ PostgreSQL Tool (n8n-nodes-base.postgresTool)
✅ Supabase (n8n-nodes-base.supabase)
✅ Airtable (n8n-nodes-base.airtable)

Integrations (9)

✅ Slack (n8n-nodes-base.slack)
✅ Gmail (n8n-nodes-base.gmail)
✅ Google Sheets (n8n-nodes-base.googleSheets)
✅ Google Drive (n8n-nodes-base.googleDrive)
✅ Microsoft Teams (n8n-nodes-base.microsoftTeams)
✅ Notion (n8n-nodes-base.notion)
✅ HTTP Request (n8n-nodes-base.httpRequest)
✅ Code Node (n8n-nodes-base.code)
✅ Wikipedia Tool (@n8n/n8n-nodes-langchain.toolWikipedia)

Control Flow (3)

✅ If Node (n8n-nodes-base.if)
✅ Switch Node (n8n-nodes-base.switch)
✅ Filter Node (n8n-nodes-base.filter)

Data Processing (5)

✅ Set Data (n8n-nodes-base.set)
✅ Merge (n8n-nodes-base.merge)
✅ Aggregate (n8n-nodes-base.aggregate)
✅ Limit (n8n-nodes-base.limit)
✅ Execution Data (n8n-nodes-base.executionData)

Workflow Management (3)

✅ Execute Workflow (n8n-nodes-base.executeWorkflow)
✅ Execute Workflow Trigger (n8n-nodes-base.executeWorkflowTrigger)
✅ Form Trigger (n8n-nodes-base.formTrigger)

File Operations (3)

✅ Read/Write File (n8n-nodes-base.readWriteFile)
✅ Compression (n8n-nodes-base.compression)
✅ Edit Image (n8n-nodes-base.editImage)

Quick Start

Prerequisites

An n8n workflow exported as JSON
Access to migrate.lamatic.ai (opens in a new tab) (or local installation)

Using the Web Interface

Upload n8n Workflow
- Navigate to migrate.lamatic.ai (opens in a new tab)
- Drag & drop your n8n JSON file onto the upload area
- Or click to browse and select a file
Processing
- Watch real-time progress as the file is processed
- See detailed migration steps and status
- Review any warnings or errors
Results
- Review the migration report with node-by-node details
- Check for any warnings or errors
- Download the converted Lamatic workflow JSON
Import to Lamatic
- Open your Lamatic Studio project
- Import the downloaded workflow JSON
- Review and test the converted workflow

Local Installation

If you prefer to run the migration tool locally:

# Clone the repository
git clone https://github.com/Lamatic/migration-tools.git
cd migration-tools

# Install dependencies
npm install

# Start development server
npm run dev

# Open in browser
# http://localhost:3000

How It Works

The migration system follows a modular pipeline architecture:

File Upload → Parser → Mapper → Dependency Builder → Generator → Output

Migration Pipeline

Parser (lib/migration/parser.ts)
- Extracts and validates n8n workflow structure from JSON
- Handles node normalization and connection parsing
- Validates workflow integrity
Mapper (lib/migration/mapper.ts)
- Converts n8n node types to Lamatic equivalents
- Maps parameters and credentials intelligently
- Supports 40+ node types with parameter transformation
Dependency Builder (lib/migration/dependencies.ts)
- Builds workflow dependency structure from n8n connections
- Handles special AI connection types
- Calculates proper execution order
Generator (lib/migration/generator.ts)
- Creates final Lamatic workflow JSON
- Validates node references
- Formats output with proper structure
Orchestrator (actions/orchestrate.ts)
- Coordinates the entire migration pipeline
- Handles error recovery and progress tracking
- Generates comprehensive migration reports

Configuration

Environment Variables

For local installations, create a .env.local file:

# Lamatic API Configuration (optional)
LAMATIC_API_KEY=your_lamatic_api_key
LAMATIC_ENDPOINT=https://api.lamatic.ai
LAMATIC_PROJECT_ID=migration-tool

# Migration Settings
MAX_FILE_SIZE=10485760  # 10MB in bytes
NODE_ENV=development

API Configuration (Optional)

If you want to automatically push migrated workflows to Lamatic:

Get Lamatic Credentials
- Sign up at lamatic.ai (opens in a new tab)
- Create a project
- Generate API key from project settings
Configure Settings
- Add your API key to .env.local
- Test the connection using the migration tool

Deployment

The migration tool is deployed at migrate.lamatic.ai (opens in a new tab) and is ready to use. If you want to deploy your own instance:

Deploy to Vercel

Push to GitHub

git add .
git commit -m "Ready for deployment"
git push origin main

Import to Vercel
- Go to vercel.com (opens in a new tab)
- Sign in with GitHub
- Click "Add New Project"
- Import your repository
Configure Environment Variables
- Add all variables from env.example
- Set NODE_ENV=production
- Add your LAMATIC_API_KEY (if using)
Deploy
- Click "Deploy"
- Your app will be live in minutes

Using Vercel CLI

# Install Vercel CLI
npm i -g vercel

# Deploy
vercel

# Set environment variables
vercel env add LAMATIC_API_KEY
vercel env add LAMATIC_ENDPOINT

# Deploy to production
vercel --prod

Other Platforms

This is a standard Next.js application and can be deployed to:

Vercel (Recommended) - Zero-config deployment
Netlify - Similar to Vercel
AWS Amplify - AWS hosting
Railway - Simple container deployment
Docker - Container-based deployment

Development

Project Structure

n8n-migration/
├── app/                    # Next.js application routes
│   ├── api/               # API endpoints
│   │   └── migrate/       # Migration API endpoint
│   ├── layout.tsx         # Root layout
│   └── page.tsx           # Main application page
├── components/            # React components
│   ├── theme-provider.tsx # Theme context provider
│   └── theme-toggle.tsx   # Theme toggle component
├── lib/                   # Core library code
│   ├── migration/         # Migration engine
│   │   ├── parser.ts      # n8n workflow parser
│   │   ├── mapper.ts      # Node type mapper
│   │   ├── dependencies.ts # Dependency builder
│   │   ├── generator.ts   # Lamatic workflow generator
│   │   ├── types.ts       # TypeScript type definitions
│   │   ├── schemas.ts     # Lamatic node schemas
│   │   └── schemaValidator.ts # Schema validation
│   └── lamatic-client.ts  # Lamatic API client
├── actions/               # Server actions
│   └── orchestrate.ts    # Main migration orchestration
├── package.json          # Dependencies and scripts
├── next.config.mjs        # Next.js configuration
├── tsconfig.json          # TypeScript configuration
└── tailwind.config.js    # Tailwind CSS configuration

Adding New Node Mappings

To add support for additional n8n node types:

Update mapping engine (lib/migration/mapper.ts)

this.addMapping({
  n8nType: 'n8n-nodes-base.newNode',
  lamaticType: 'lamatic_equivalent',
  isSupported: true,
  parameterMappings: [
    { n8nParameter: 'param1', lamaticParameter: 'param1', required: true }
  ],
  credentialMappings: [
    { n8nCredential: 'cred1', lamaticCredential: 'cred1', requiresReauth: true }
  ],
  notes: 'Description of the mapping'
});

Add node creation logic in createLamaticNode() method
Update schemas (lib/migration/schemas.ts) if needed
Test with your own n8n workflow

Architecture

Each component is independently testable and handles specific responsibilities:

Parser: Validates and normalizes n8n structure
Mapper: Converts node types and parameters
Dependency Builder: Resolves connections and execution order
Generator: Creates final Lamatic JSON structure

Troubleshooting

Common Issues

"Invalid n8n workflow"

Solutions:

Ensure file is valid JSON
Check n8n workflow structure
Verify file isn't corrupted
Try exporting the workflow again from n8n

"File size exceeds limit"

Solutions:

Reduce file size (max 10MB)
Remove unnecessary nodes
Compress the JSON file
Split large workflows into smaller ones

"Migration failed"

Solutions:

Check migration report for details
Verify n8n workflow is valid
Try with simpler workflow first
Check browser console for detailed errors

"No trigger node found"

Solutions:

Ensure workflow contains a valid trigger node
Supported triggers: webhook, manual, schedule, chatTrigger
Verify trigger node is properly configured in n8n

Debug Mode

Enable debug logging for local development:

NODE_ENV=development npm run dev

Check browser console for detailed error messages and migration progress.

API Reference

Migration Pipeline

import { processMigration } from '@/actions/orchestrate';

const result = await processMigration(file);
// Returns: MigrationResult with success status, nodes, and workflow

Individual Components

// Parse n8n workflow
import { N8nParser } from '@/lib/migration/parser';
const parser = new N8nParser();
const workflow = parser.parseWorkflow(jsonContent);

// Map nodes to Lamatic
import { NodeMapper } from '@/lib/migration/mapper';
const mapper = new NodeMapper();
const result = mapper.mapNode(n8nNode, nodeId);

// Build dependencies
import { DependencyBuilder } from '@/lib/migration/dependencies';
const builder = new DependencyBuilder();
const deps = builder.buildDependencies(workflow, nodes);

// Generate Lamatic workflow
import { LamaticOutputGenerator } from '@/lib/migration/generator';
const generator = new LamaticOutputGenerator();
const lamaticWorkflow = generator.generateWorkflow(
  nodes,
  workflow,
  metadata,
  connections
);

Best Practices

Before Migration

Backup Your Workflows: Always keep a backup of your original n8n workflows
Test with Simple Workflows: Start with simple workflows to understand the process
Review Node Support: Check if all your nodes are supported before migrating
Document Dependencies: Note any external dependencies or credentials needed

During Migration

Review Warnings: Pay attention to migration warnings and address them
Check Node Mappings: Verify that nodes are mapped correctly
Validate Connections: Ensure workflow connections are preserved
Test Incrementally: Migrate and test workflows one at a time

After Migration

Test Thoroughly: Test all migrated workflows in Lamatic
Verify Credentials: Re-authenticate any required credentials
Check Data Flow: Verify data flows correctly through the workflow
Update Documentation: Update any workflow documentation

Support

Getting Help

Check Documentation
- Code comments and type definitions
- Component documentation in the repository
Test Your Workflow
- Upload your own n8n workflow JSON file
- Verify the migration works correctly
Report Issues
- Open an issue on GitHub (opens in a new tab)
- Include your workflow JSON (sanitized if needed)
- Describe the issue and expected behavior

Resources

Happy Migrating! 🚀

Feedback API GraphQL API ↗

Was this page useful?

Questions? We're here to help

Feedback Email Talk to sales

n8n to Lamatic Migration Tool

Overview

Key Benefits

Features

File Upload

Intelligent Node Mapping

Dependency Analysis

Real-time Progress

Migration Reports

Error Handling

Supported n8n Nodes

Triggers (4)

AI & LangChain (6)

Database & Tools (3)

Integrations (9)

Control Flow (3)

Data Processing (5)

Workflow Management (3)

File Operations (3)

Quick Start

Prerequisites

Using the Web Interface

Local Installation

How It Works

Migration Pipeline

Configuration

Environment Variables

API Configuration (Optional)

Deployment

Deploy to Vercel

Using Vercel CLI

Other Platforms

Development

Project Structure

Adding New Node Mappings

Architecture

Troubleshooting

Common Issues

"Invalid n8n workflow"

"File size exceeds limit"

"Migration failed"

"No trigger node found"

Debug Mode

API Reference

Migration Pipeline

Individual Components

Best Practices

Before Migration

During Migration

After Migration

Support

Getting Help

Resources

Was this page useful?

Questions? We're here to help

Subscribe to updates
