Integration Guide

This guide provides step-by-step instructions for integrating Lamatic.ai into your application. You can trigger workflows programmatically from any application that can make HTTP requests, including web applications, mobile apps, backend services, and serverless functions.

Integration Overview

Lamatic.ai integrates with your application through GraphQL API endpoints. This approach provides a standardized and efficient way to interact with our platform, enabling you to execute your GenAI flows on-demand or as part of larger application flows.

Required Information

Before integrating, gather the following information from your Lamatic Studio:

API Key: Your authentication key (from Studio > Settings > API Keys) - Learn how to get your API key
Project ID: Unique identifier for your project (found in project settings)
Project URL: Your GraphQL endpoint URL (provided in your project dashboard)
Workflow ID: The ID of the specific workflow you want to trigger (visible in the workflow editor)

Integration Steps

Step 1: Set Up Environment Variables

Store your API key securely as an environment variable. Never hardcode credentials in your source code.

For local development:

Create a .env file (add it to .gitignore)
Add: LAMATIC_API_KEY=your_api_key_here

For production:

Use your platform's secret management system (AWS Secrets Manager, Azure Key Vault, etc.)
Or set environment variables in your deployment configuration

Step 2: Install Required Dependencies

Depending on your technology stack:

JavaScript/Node.js: npm install axios or npm install node-fetch
Python: pip install requests
Other languages: Use your language's standard HTTP client library

Step 3: Configure Request Headers

Every request must include these headers:

{
  "Authorization": "Bearer YOUR_API_KEY",
  "Content-Type": "application/json",
  "x-project-id": "YOUR_PROJECT_ID"
}

Step 4: Structure Your GraphQL Query

Use the executeWorkflow mutation with your workflow ID and payload:

query ExecuteWorkflow($workflowId: String!, $payload: JSON) {
  executeWorkflow(workflowId: $workflowId, payload: $payload) {
    status
    result
  }
}

Step 5: Map Your Data to Workflow Inputs

Ensure your payload matches the input schema defined in your workflow. Check your workflow's input variables in the Studio to ensure correct field names and types.

Step 6: Handle Responses and Errors

Always implement proper error handling:

Check HTTP status codes
Parse GraphQL errors from the response
Handle network failures gracefully
Implement retry logic for transient failures

Code Examples

Here's how to trigger a workflow using GraphQL in different programming languages:

Note: In these examples, we're using url as a payload variable. You should adjust the payload variables based on your workflow's input requirements.

const axios = require('axios');

// Step 1: Get your API key from environment variable
const lamatic_api_key = process.env.LAMATIC_API_KEY;

// Step 2: Define your GraphQL query
const query = `
query ExecuteWorkflow(
$workflowId: String!
$url: String
) {
executeWorkflow(
  workflowId: $workflowId
  payload: {
    url: $url
  }
) {
  status
  result
}
}
`;

// Step 3: Define your query variables
const variables = {
workflowId: "YOUR_WORKFLOW_ID",
url: "url"
};

// Step 4: Configure the request
const options = {
method: 'POST',
url: 'YOUR_PROJECT_URL',
headers: {
'Authorization': `Bearer ${lamatic_api_key}`,
'Content-Type': 'application/json',
'x-project-id': 'YOUR_PROJECT_ID',
},
data: {
query,
variables
}
};

// Step 5: Make the request
axios(options)
.then(response => {
console.log('Success:', response.data);
})
.catch(error => {
console.error('Error:', error.response?.data || error.message);
});

Understanding the Response

The response structure can be configured in the Schema of the GraphQL Response node in your workflow. The response will follow this structure:

{
  "data": {
    "executeWorkflow": {
      "status": "success",
      "result": {
        // Your custom output as configured in the Schema
      }
    }
  }
}

Common Integration Patterns

Synchronous Integration: Make a request and wait for the response before proceeding. Best for workflows that complete quickly.

Asynchronous Integration: Trigger the workflow and handle the response in a callback or promise. Best for longer-running workflows.

Webhook Integration: Configure your workflow to send results to a webhook endpoint in your application. Best for workflows that may take time to complete.

Batch Processing: Trigger multiple workflows in parallel or sequence. Ensure you respect rate limits.

Troubleshooting

Authentication Errors (401)

Verify your API key is correct and not expired
Check that the API key is properly set in environment variables
Ensure the Bearer prefix is included in the Authorization header

Project Not Found (404)

Verify your Project ID is correct
Check that the Project URL is correct
Ensure your project is deployed

Workflow Execution Errors

Verify the Workflow ID is correct
Check that payload structure matches workflow inputs
Review workflow logs in the Studio

Network Errors

Check your internet connection
Verify the Project URL is accessible
Check firewall settings
Implement retry logic with exponential backoff

Important Notes

Workflow ID: You can find your workflow ID in the Studio when viewing your workflow
Payload Variables: The payload object should match the input variables defined in your workflow. In this example, we're using url, but you should adjust this based on your workflow's requirements
Error Handling: Always check the response status and handle errors appropriately in your application
API Key Security: Never commit your API key to version control. Always use environment variables or secure secret management
