Vector Action Node Documentation

The Vector Action Node enables users to index, filter, and delete data from vector databases. These actions form the core of vector-based data workflows in Lamatic.

Features

Key Functionalities

Multi-Action Capability: Choose between indexing, filtering, or deleting records in a vector DB.
Conditional Filtering: Apply advanced JSON filters with logical operators (And, Or, etc.).
Primary Key Matching: Use custom primary keys to uniquely identify or filter/delete entries.
Duplicate Handling: Choose to overwrite or skip on indexing conflicts.

Benefits

Flexibility: Handle multiple vector operations within one node.
Control: Fine-tune data updates with filters and duplication settings.
Efficiency: Manage large vector datasets with scalable indexing and deletion.
Search Precision: Use rich metadata and filters to retrieve exactly what’s needed.

What Can You Build?

Automate document indexing pipelines.
Build search interfaces with filterable vector data.
Clean up or update vector DBs programmatically.

1. Index Action

Indexes vectors and metadata into the selected vector database.

Configuration Reference

Parameter	Description	Required	Example Value
Vector DB	Select the vector database where the vectors will be indexed.	Yes	`database`
Vectors	Enter the vector data to be indexed in the database.	Yes	`{{codeNode_540.output.vectors}}`
Metadata	Include additional information to enhance vector search and retrieval.	Yes	`{{codeNode_540.output.vectors}}`
Primary Keys (JSON)	Provide unique identifiers for each vector in JSON format.	Yes	[]
Duplication Records	Manage duplicates by choosing to `overwrite` or `skip` them.	No	`overwrite`

Low-Code Example

- nodeId: IndexNode_543
    nodeType: IndexNode
    nodeName: Index to DB
    values:
      vectorDB: IndexCrawler
      webhookURL: https://webhook.site/685a66e7-b4d3-40a4-9801-99e3460414f9
      primaryKeys: ''
      vectorsField: '{{codeNode_540.output.vectors}}'
      metadataField: '{{codeNode_540.output.metadata}}'
      duplicateOperation: overwrite
      embeddingModelName: {}
      generativeModelName:
        type: embedder/text
        nodeId: IndexNode
        model_name: text-embedding-ada-002
        provider_name: openai
    needs:
      - codeNode_540

Output

recordsIndexed: An integer indicating the number of records successfully indexed.
duplicateRecordsDeleted: An integer representing the number of duplicate records removed during the indexing process.
message: A string providing a status or summary of the indexing operation.

Example Output

 {
    "recordsIndexed": 1,
    "duplicateRecordsDeleted": 0,
    "message": "Data indexed successfully"
  }

2. Filter Action

Filters indexed records using metadata and/or vector queries.

Configuration Reference

Parameter	Description	Required	Example
vectorDB	Target vector database	Yes	`CallData`
action	Must be set to `filter`	Yes	`filter`
filters	JSON filter using logical operators and conditions	Yes	See below
limit	Number of results to return	No	`20`

Example

- nodeId: vectorNode_2
  nodeType: vectorNode
  nodeName: VectorDB
  values:
    vectorDB: CallData
    action: filter
    vectorsField: '[]'
    metadataField: '[]'
    primaryKeys: ['topic']
    duplicateOperation: overwrite
    filters: |-
      {
        "operator": "And",
        "operands": [
          {
            "path": ["topic"],
            "operator": "Equal",
            "valueText": "Topic1"
          }
        ]
      }
    limit: 20

Output

success: A boolean indicating if the filter operation was successful.
data: An array of records matching the filter criteria.
count: The number of records returned by the filter operation.

Example Output

{
    "success": true,
    "data": [
      {
        "title": "Lamatic Docs",
        "content": "Welcome to the Lamatic documentation!",
      }
    ],
    "count": 1
  }

3. Delete Action

Deletes records matching filter criteria.

Configuration Reference

Parameter	Description	Required	Example
vectorDB	Target vector database	Yes	`CallData`
action	Must be set to `delete`	Yes	`delete`
filters	JSON filter for selecting items to delete	Yes	See below
primaryKeys	Optional fields used to match entries for deletion	No	`["topic"]`

Example

- nodeId: vectorNode_3
  nodeType: vectorNode
  nodeName: VectorDB
  values:
    vectorDB: CallData
    action: delete
    vectorsField: '[]'
    metadataField: '[]'
    primaryKeys: ['topic']
    duplicateOperation: overwrite
    filters: |-
      {
        "operator": "And",
        "operands": [
          {
            "path": ["topic"],
            "operator": "Equal",
            "valueText": "Topic1"
          }
        ]
      }
    limit: 20
  needs:
    - triggerNode_1

Output

deletedCount: Number of records successfully deleted.
matches: Number of records that matched the filter criteria.
failed: Number of records that failed to delete.

Example Output

{
    "deletedCount": 2,
    "matches": 2,
    "failed": 0
}

Troubleshooting

Common Issues

Problem	Solution
Invalid Vector DB	Ensure the database name exists and is spelled correctly.
Missing Embeddings	Make sure vectors are provided or an embedding model is configured.
Misconfigured Filters	Ensure filters use valid JSON and correct field paths and operators.
Primary Key Conflicts	Resolve using `overwrite` or `skip` options for handling duplicates.
